This is the version that meets 100% of the safety standards for its occupants, with the same reliability and power standards as race models, but it is designed to be more comfortable for outdoor life. It includes a communication system between the driver and co-driver with headphones and a microphone, among many other details that make off-road life much more enjoyable. It also comes with two engine maps, one for urban use and one for off-road conditions.
VW 1.0L Charged TSI EA211 3 Cylinders 1.0 turbo
The 1.0 TSI, Volkswagen's compact marvel from the EA211 series, debuted in 2015, marking VW's ambitious downsizing. Tailored for models like the VW Polo Mk6 and Golf Mk7, it flaunts a die-cast aluminum block, a unique open-deck design, and a powerful 3-cylinder turbocharged heart. With features mirroring its 1.4 TSI sibling, its aluminum cylinder head integrates an exhaust manifold, ensuring rapid warm-ups. Its precision-engineered internals, including a vane-type oil pump and a turbocharger, underscore its efficiency, all orchestrated by the Bosch Motronic ME 17.5.21.
The same differential housing is used in both the front and rear differential. It lowers the part costs needed to tackle a rally.
The well know ETV full sequential gear box from 3MO have be tailored with dedicated gear ratio and drop gear to deliver best acceleration to the maximum speed of 135 km/h whatever the road conditions.
The gearbox is links with the engine with Tilton clutch system. 2 options are available:
the lubrication is ensured by a mechanical oil pump with internal lubrication system or with splash lubrication technology. A 4+4 discs version (up to 16 friction faces) of the self-locking differential is available
The current breaking package offer with its specific 4 pistons caliber and 20.5 mm disk an unequal breaking capability in the Challenger class vehicle and endless breaking endurance.
DAKAR II Braid rims offer a very competitive package with the 32” BF Goodrich KDR 3 for Baja and sandy road.
KMC EVO3 - Red Bull Off-Road Junior Team (each) Direct collaboration with the Red Bull Off Road Junior Team drivers / engineers and the KMC factory engineers. This is the EVO3 wheel that has been tested and refined over the last couple years -
TENSOR: Recently tested at the Portugal Rally 2023 The Dakar is a cross-country style rally and one of the most difficult motorsport events in the world. Cross-country rallies also known as “Rally Raid” events, consist of timed off-road stages called Specials and transit sections which move the competitors between specials and the service camp known as the Bivuoac. At several times during the event, the Bivuoac will move to different locations requiring the entire population of the rally including organization assets and team service vehicles to the new location. Check out the below gallery of scenes from the Dakar Rally
BF GOODRICH: Tested in the deserts of Baja California, Mexico, and southwestern United States by championship-winning drivers, the 40x12.50R18 Baja T/A KR3 again raises the bar for the most successful brand in desert racing history: BFGoodrich. These tires are designed, engineered and made in the U.S.
Standard Taurus Cooling Pack 2024
Caming Soon: With 2024 regulation, the intercooler design is now free, and give us the opportunity to improve the cooling performance with an optional intercooler design in collaboration with PWR. The benefits are lower inlet manifold temperature and reduced pressure drop allowing stronger low end torque and high end performances
R330
• Hole interaxis: 6x70 mm.• Leather upholstery.
R350 Suede
350 mm diameter
- 6x70mm slot spacing
- Suede coating
- IP68 buttons for water and dust protection
R353 Flat
Flat steering wheel with large grip.
Suede.
Hole interaxis: 6x70 mm.
R350 Suede 6 selection butons
6 selection butons ( turning light - horn - light - speed limiter activation - trigger)
Full Tank 130 lits in Composite, 4 Pumps -14 KG (May be height spaces for the driver)
Sparco Circuit QRT:
Homologation: FIA 8855-1999
Material: QRT
Ideal for Touring and Rally races
- Non-slip fabric for shoulder and seat restraint
- Divisible legrest and seat cushion
- Available in 2 sizes (Circuit II size L), with integrated HRS (Head Restraint System).
Fixed using M8 lateral fastenings with 290 mm spacing.
Weight: 8,6 kg
Sparco ADV ELITE.
Giving top-level performance and an evolution of the ADV-SCX, the frame design has a structural as well as an aesthetic function and, together with an energy-absorption system, gives the seat unrivalled impact resistance. The reduced thickness of the frame and improvements to the head restraint, together with the carefully researched ergonomics of the padding, increase its habitability and comfort. Fixed using lateral fastenings with 290mm spacing.
Weight:
- Shell 7.810g
- Seat 10.300g
The seat is homologated in conjunction with the side mounting frames 004988ADV (sold separately)
OMP HTE EVO
FIA 8855-1999 homologated fiberglass seat. Innovative ultraprotective shell inspired by the multi world champion OMP HTE ONE seat. High protection and containment, designed to accomodate various heights. Large shoulder harness slots. Upholstering in velour and Airnet
SPARCO:
- 6 point harness
- 2'' FHR specific straps
- Compact T-bar
- Aluminium buckle
- Aluminium adjusters
- Rollcage fasteners (shoulders and thigh) and ultra-light karabiner (abdominal)
OMP :
SUPERLIGHT PROFESSIONAL SAFETY BELT
Lightweight and comfortable safety harness for saloon cars in polyester fabric. Forged aluminium ultralight adjusters, buckle in ergal machined from solid and magnesium. The Harness ensures best safety level ever thanks to the ultra-resistant buckle with an anti-unwitting opening system and exclusive double pin T-bar crotch attachments. FHR only.
Standard: PC950 34Ah Odyssey Extreme 12V, 400A SAE
Super B: Optional lithium battery allows to save 1kg compare to a standard battery and increase the available power in the car.
Light Pack: Osram led side light and Lazer led 18
Premium Kit: Lazer Carbon 4 side light and Lazer Linear -18Elite + (W+Y)
The 2024 units come with the "Lazer" light kit. The customer can add in his initial purchase an extra light kit as well as an extra complementary light kit to enhance the view in dunes and on circuits that require extra lighting power.
Adds approximately 15 kg to the car. The windshield wiper system is delivered installed. Tempered glass.
After completing your order, our design team will contact you to outline the custom design of your T3
